Modbus RTU interface card for EASYdrive The MODBUS bus system belongs to the fieldbus family.As a rule, the network is built up in a linear structure.The maximum data transfer rate on a MODBUS can be up to 115.2 kbit / s.The fieldbus cable is only connected via the M12 connector on the front or.If the fieldbus line is to be forwarded to another subscriber, an M12 T distributor must be used.The bus must be terminated with a terminating resistor. The interface card is part of the innverter. All product photos are non-binding examples! Technical changes reserved.

CANopen interface card for EASYdrive. The CANopen bus system belongs to the fieldbus family and is based on the CAN bus (Controller Area Network). As a rule, the network is built up in a linear structure. The maximum data transfer rate on a CANopen bus can be up to 1 Mbit / s and depends on the cable length. A maximum of 127 participants may exist in the bus association. Including M12 connection cable open 2 m, M12 connector / open / CANopen / 5-pin / 2 m / A-coded. The interface card is part of the converter and cannot be retrofitted. All product photos are non-binding examples! Technical changes reserved.

LS CANOpen interface card only for S100, IS7, IP5A or G100. Please select series. All product photos are non-binding examples! Technical changes reserved.

LS PROFINET interface card only for S100 or IS7. Please select series. All product photos are non-binding examples! Subject to technical changes.

LS EtherCAT interface card only for S100. All product photos are non-binding examples! Technical changes reserved.

LS Profibus interface card only for S100, IS7 or G100. Please select series. All product photos are non-binding examples! Technical changes reserved.

Profibus interface card for EASYdrive. Communication interface. With the help of PROFIBUS, devices from different providers can be customized communicate. PROFIBUS independently distinguishes between master and slave devices, so that multi-master operation is also possible. Including M12 connection cable open 2 m, M12 connector / open / Profibus / 5-pin / 2 m / B-coded. -The interface card is part of the converter and cannot be retrofitted. All product photos are non-binding examples! Technical changes reserved.

EtherCAT interface card for EASYdrive. The EtherCAT bus system belongs to the fieldbus family. Usually the network is in linear structure. The maximum data transfer rate on an EtherCAT bus can up to 100 Mbit / s. The fieldbus line is only connected via the two M12 connection sockets on the front. It should be noted that the incoming bus line to the "In" socket and the outgoing line to the "Out" socket can be connected. If it is the last participant, the "Out" socket is free to leave - a terminating resistor is not required. Including M12 connecting cable 2 m, M12 connector / RJ45 connector / 4-pin / 2 m / D-coded. The interface card is part of the converter and cannot be retrofitted. All product photos are non-binding examples! Technical changes reserved.
