Electric motor IE3 160M-8, 4,0 kW, 8 pol, B3

Electric motor, Power= 4 kW, Speed= 750 tpm, Type= B3 Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz, Efficiency class= IE3, Efficiency= 84.8%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC-Thermistors, Weight= xx kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available). The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives. The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£456.52*

Details

Electric motor IE3 160M-8, 4,0 kW, 8 pol, B5

Electric motor, Power=4 kW, Speed=750 rpm, Design=B5 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=84.8%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The Electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£470.21*

Details

Electric motor IE3 160M-8, 4,0 kW, 8 pol, B35

Electric motor, Power=4 kW, Speed=750 rpm, Design=B35 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=84.8%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The Electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£479.34*

Details

Electric motor IE3 160M-8, 5,5 kW, 8 pol, B3

Electric motor, Power=5.5 kW, Speed=750 rpm, Design=B3 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=86.2%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The Electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£536.33*

Details

Electric motor IE3 160M-8, 5,5 kW, 8 pol, B5

Electric motor, Power=5.5 kW, Speed=750 rpm, Design=B5 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=86.2%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The Electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£552.41*

Details

Electric motor IE3 160M-8, 5,5 kW, 8 pol, B35

Electric motor, Power=5.5 kW, Speed=750 rpm, Design=B35 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=86.2%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The Electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£563.13*

Details

Electric motor IE3 160M-6, 7,5 kW, 6 pol, B3

Electro motor, Three-phase motor, Power= 7,5 kW, Speed= 1000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 89,1%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£566.50*

Details

Electric motor IE3 160M-6, 7,5 kW, 6 pol, B5

£583.49*

Details

Electric motor IE3 160M-6, 7,5 kW, 6 pol, B35

£594.81*

Details

Electric motor IE3 160M-2, 11 kW, 2 pol, B3

Electro motor, Three-phase motor, Power= 11 kW, Speed= 3000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,2%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 109,0kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£595.00*

Details

Electric motor M3 160L-11 kW-6pole-B35

Electro motor, Three-phase motor, Power= 11 kW, Speed= 1000 rpm Voltage= 3 x 400/690 V-50 Hz, 3 x 460/795 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 89,1%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 132 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= fixed potted (if present).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 or IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£605.70* £807.60* (25% saved)

Details

Electric motor IE3 160M-2, 11 kW, 2 pol, B5

Electro motor, Three-phase motor, Power= 11 kW, Speed= 3000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,2%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 109,0 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£612.85*

Details

Electric motor IE3 160M-2, 11 kW, 2 pol, B35

Electro motor, Three-phase motor, Power= 11 kW, Speed= 3000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,2%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 109,0 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£624.75*

Details

Electric motor IE3 160M-4, 11 kW, 4 pol, B3

Electro motor, Three-phase motor, Power= 11 kW, Speed= 1500 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,4%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available). The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives. The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£625.37*

Details

Electric motor IE3 160L-8, 7,5 kW, 8 pol, B3

Electric motor, Power=7.5 kW, Speed=750 rpm, Design=B3 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz. Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=87.3%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, cooling=axial fan (plastic), motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£628.61*

Details

Electric motor IE3 160M-4, 11 kW, 4 pol, B5

Electro motor, Three-phase motor, Power= 11 kW, Speed= 1500 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,4%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 118,0 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£644.15*

Details

Electric motor IE3 160L-8, 7,5 kW, 8 pol, B5

Electric motor, Power=7.5 kW, Speed=750 rpm, Design=B5 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz. Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=87.3%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£647.47*

Details

Electric motor IE3 160M-4, 11 kW, 4 pol, B35

Electro motor, Three-phase motor, Power= 11 kW, Speed= 1500 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,4%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 118,0 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£656.64*

Details

Electric motor IE3 160L-8, 7,5 kW, 8 pol, B35

Electric motor, Power=7.5 kW, Speed=750 rpm, Design=B35 Shaft=42 x 110 mm, Voltage=3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency=50/60 Hertz. Frequency=50/60 Hertz, Efficiency class=IE3, Efficiency=87.3%, Paint=RAL 5010 (gentian blue), Protection class=IP55, Temperature sensor=3 x PTC thermistor, Weight=xx kg, Operating mode=S1- 100% ED, Terminal box position=top, Housing=gray cast iron, Insulation class=F (155°C), Ball bearings=SKF or equivalent, Cooling=axial fan (plastic), Motor feet=firmly cast (if available). The engine mounting is designed for clutch operation. For belt drives, we recommend reinforced cylindrical roller bearings The electric motor is for that Frequency inverter - Use and suitable for both directions of rotation. According to VDE 0105 and IEC 364, all work on the electric drive can only be carried out by qualified personnel to be carried out by qualified personnel. If you require modifications or special designs, please send an inquiry. All product photos are non-binding examples! Technical changes reserved.

£660.04*

Details

Electric motor IE3 160M2-2, 15 kW, 2 pol, B3

Electro motor, Three-phase motor, Power= 15 kW, Speed= 3000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,9%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£660.38*

Details

Electric motor IE3 160M2-2, 15 kW, 2 pol, B5

Electro motor, Three-phase motor, Power= 15 kW, Speed= 3000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 91,9%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 128 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£680.18*

Details

Electric motor IE3 160L-4, 15 kW, 4 pol, B3

Electro motor, Three-phase motor, Power= 15 kW, Speed= 1500 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 92,1%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£687.64*

Details

Electric motor IE3 160L-6, 11 kW, 6 pol, B3

Electro motor, Three-phase motor, Power= 11 kW, Speed= 1000 rpm Shaft= 42 x 110 mm, Voltage= 3 x 400/690 V-50 Hz, 3 x 480/830 V-60 Hz (± 5% according to VDE 0530), Frequency= 50/60 Hertz. Efficiency class= IE3, Efficiency= 90,3%, Paint= RAL 5010 (gentian blue), Degree of protection= IP55, Temperature sensor= 3 x PTC thermistors, Weight= 139 kg, Operating mode= S1- 100% DC, Terminal box position= top, Housing= Cast iron, Insulation class= F (155°C), Ball bearing= SKF or equivalent, Cooling= axial fan (Plastic), Motor feet= screwable (if available).The engine mounting is designed for clutch operation. We recommend reinforced Cylindrical roller bearings for belt drives.The Electric motor is suitable for frequency converter use and for both directions of rotation. According to VDE 0105 bzw. IEC 364 all work on the electric drive must only be carried out by qualified specialist personnel. For modifications or special designs please send inquiry. All product photos are non-binding examples! Technical changes reserved.

£687.64*

Details

Electric motor IE3 160M2-2, 15 kW, 2 pol, B35

£693.39*

Details

Electric motors in the power range from 4.0 kW - 500 kW

JS-Technik GmbH specialises in a wide range of challenges in the field of professional drive technology with a focus on electric motors, frequency inverters and geared motors. On this page you will find a selection of electric motors in grey cast iron design in sizes 160 - 355 and with outputs of 4 kW, 5.5 kW, 7.5 kW, 11 kW, 15 kW, 18.5 kW, 22 kW, 30 kW, 37 kW, 55 kW, 75 kW, 90 kW, 110 kW, 160 kW, 200 kW, 250 kW, 315 kW, 355 kW, 400 kW, 450 kW, 500 kW. These motors are available in different speeds, i.e. motors with pole numbers of 2, 4, 6, 8 or 10. For three-phase motors, the rated voltage has been extended from 380 V to 400 V.

Three-phase motor with 2 motor shafts

Duty cycle of electric motors

You can purchase JS drive systems with the following duty cycles: S1 (continuous operation), S2 (short-time operation), S3 (intermittent operation without starting, without braking), S4 (intermittent operation with starting, without braking), S5 (intermittent operation with electrical braking, with starting), S6 (continuous operation with intermittent load=time under load followed by a time without load without motor standstill), S7 (continuous operation with electrical braking), S8 (continuous operation with periodic load and speed changes).

Medium voltage motor

Medium-voltage motors

Design and terminal box

The design of the JS motors is variable on request. The motor feet can also be modified for heavy-duty AC motors, i.e. from 4 kW to 500 kW. This means that a B3 foot motor can also be converted into a B5 flange motor or a B4/B5 foot/flange motor. Another advantage is that the drive system can be modified to a system with a terminal box at the top, left, right or even at the bottom.

Motor with special paint finish

Efficiency classes for asynchronous motors

You can also purchase JS energy-saving motors in IE3. The most important efficiency classes are IE1, IE2 and IE3. The legal requirements for minimum efficiency are as follows: Since 16 June 2011, the minimum efficiency of motors (0.75 kW - 375 kW) must comply with efficiency IE2. Since 1 January 2015, the minimum efficiency of motors (7.5 kW - 375 kW) must correspond to IE2 efficiency, or the motors must be operated as IE3 with a frequency converter. Since 1 January 2017, the minimum efficiency of motors (0.75 kW - 375 kW) must correspond to IE2 efficiency, or the motors must be operated as IE3 with a frequency inverter.

Your specialist for electric motors

In many cases, electric motors have to be customised. With our qualified staff, our large stock of motors and gearboxes and our own final assembly, we are the perfect partner for companies that require external expertise in a wide range of areas - whether it's a specific brake motor, circular saw motor, electric motor with frequency inverter, motors with a variable number of poles or reduced progressive motors. In addition, our large stock of worm gearboxes and electric motors enables us to offer particularly short delivery times.

Motor in special design

An electric drive can also be equipped with various extras. Here we modify and customise the output shaft, the shaft height, the foot dimensions, a specific bearing, a backstop, the terminal box or speed monitoring. We also install temperature monitoring with PT100, PTC thermistor or thermosensor. Different types of protection such as IP54, IP55, IP56, IP65, tropical protection, special winding, special voltage, rain protection cover, heating at standstill, cooling with forced cooling fan and much more can also be realised.
